用处与百度百科/Brief Introduction：

这手机主要利用了异常三通管件包装阀，常使用在水剂和膏霜类的产品的包装，特备对高黏度物品（如浓酱、辣子酱、番茄酱、种衣剂、微乳剂、浮悬剂等）的目的更加特别，且导致精度较高。这手机主要利用了PLC可源程序操控，和6英尺接触屏组排菜单栏平台，履行自己的进瓶，自己的包装，自己的出瓶，电嚣，气动弹簧元部件均主要利用了国际性品脾，为了保持了非常出色的安全能和男人持久稳定性高的能。本机器构造十分简单，的操作利于，是境内很好的真对高黏度物品的包装机器。这手机配用了阻止漏滴与磨砂的包装闷头，为了保持包装完成后后无漏滴，无磨砂。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

基本特征/Characteristic：

◆把控好平台——采取三菱数控程序PLC把控好平台，装罐极量随机的调准。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆使用表面——65英寸彩屏手触式使用表面，形象容易、安全保障不靠谱Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆基本功效调整——排料有防滴漏问题提升装置，可结合原辅料性能特点享有下潜分装基本功效。（此基本功效不错建议选用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电器pcb板pcb板——均通过香港国际项目项目，抓好环保设备的安全保障信得过、精确度性强；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机戒机械部位——服务器机械部位均使用高质量304不锈碳钢作,如果是需要接触的面积原辅料会使用316L另记账用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆数值器监测——立即数值器，对事情总产值更直观表示。Counting test, real-time, intuitive reflect the yield of work.◆包装检则——无瓶不灌、瓶数跟不上不灌Bottle filling test - no bottle no filling, not enough◆服务器维保情况下——远程服务器遵循GMP的标准，可枯燥拆下、难以清理服务器维保。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆置换产品规格型号——撤换罐装产品规格型号时，只需要轻松自在调正，轻松自在拿出。Changing specifications - change the filling specifications, simply adjust, easy fix.◆低能耗增加——增加了低能耗方框，使电脑的操作的场景十分清理卫生管理。（此低能耗增加能够 选购）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技術主要参数/technical parameters：

罐装头数The number of filling head	8头（可选装4、6、8、10、13个灌装设备头）8 head♈ (optional 4, 6, 🍸8, 10, 12 filling head)
采用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量检验精确measure precision	±1%
罐装发热量Canned capacity	150-1000ml
产出意识Production Capacity	2400-4000瓶/h2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
